860 - 960 MHz, 96-EPC Bits, extensible to 496 Bits, 64 Bit Unique TID, UHF Inlay

Chip: Alien H3
Die Cut Size: 19mm*93mm
Antenna Material: Copper
Reading Distance: 4.4M
Application: Car Management
Windshield application may up to 20 meters

The Alien Technology Custom Command UHF Labels Alien ALN-9654 UHF RFID Tag is a general purpose RFID inlay optimized for tagging glass, plastic and similar high dielectric materials such as windshields and reusable plastic containers and pallets.

Technology

Meets EPCglobal Gen 2 (v 1.2.0) as well as ISO/IEC 18000-6C
Worldwide operation in the RFID UHF Bands(860-960Mhz)
Higgs-3 IC with 800-bits of NonVolatile Memory
– 96 EPC bits, extensible to 480-bits
– 512 User bits
– 64-bit Unique TID
– 32-bit Access and 32-bit Kill passwords
Pre-programmed with a unique, unalterable 64-bit serial number
User Memory can be Block Perma-Locked as well as read password protected in 64-bit blocks
Supports all Mandatory and Optional Gen 2 Commands including Item Level
Custom Command for high speed programming
Exceptional Operating Range
Available in high-yield, high-capacity rolls for high-volume converting processes

Product Overview:

Powered by Alien®’s break-through Higgs™3 UHF RFID IC and innovative antenna design, the ALN-9654 delivers industry leading EPC Gen 2 performance and reliability.

ALN-9654 inlays are World Tag compliant, enabling consistent operation across the diverse frequencies of the Americas, Europe, Middle East, Asia, and Africa.

With its Higgs-3 core, the “G” delivers ultra-high, “best-of-breed” performance. It is especially wellsuited for challenging materials with high-dielectrics, such as plastic and glass (hence the “G” nickname).

The “G” inlay comprises a rich feature set including a 32-bit TID, a 64-bit Unique TID for authentication and serialization applications, an extensible EPC memory bank, 512-bits of user memory for distributed data applications, and password protected read and write support capabilities to prevent unauthorized viewing and modifi cation of the tag’s data.

Higgs™-3

• Meets EPCglobal Gen2 (V 1.2.0) as well as ISO/IEC 18000-6C
• Worldwide operation in the RFID UHF bands (860-960 MHz)
• 800-Bits of Nonvolatile Memory
  • 96-EPC Bits, extensible to 480 Bits
  • 512 User Bits
  • 64 Bit Unique TID
  • 32 Bit Access and 32 bit Kill Passwords
• Pre-Programmed with a unique, unalterable 64-bit serial number
• User Memory can be Block Perma-Locked as well as read password protected in 64 Bit Blocks
• Supports all Mandatory and Optional Commands including Item Level Commands
• Custom Commands for high speed programming; 30 tags per second for the 96-bit EPC number
• Low power operation for both read and program
• Exceptional operating range, up to 10m with appropriate antenna

Applications

• Windshield glass

• Reusable plastic pallets

• Totes and containers

• Asset management

• High speed motocross and triathlon tagging
